Muthing MU-E Vario

Front or Rear-Mounted

For Compact and Multi Purpose Tractors up to 60 HP

Standard Equipment

  • Purposely designed hood in conjunction with high rotor and cutting speeds and a removable shredding bar spreads the shredded material evenly behind the roller giving an excellent Mulching and Shredding Quality
  • Made from High Quality Steel QST/S with specially designed Head-Stock Cat. I for Front or Rear mounting, shiftable Mounting position near to the tractor, Head-Stock adaptable to different positions
  • Patented removable shredding bar system (Shark Fin)
  • Market-leader in foreign object thrown test results
  • Gear box with integrated over-run-clutch and through-drive for 540 / 1,000 r.p.m., centred on top of the hood
  • P.T.O. shaft; Belt protection with tension measuring slot
  • M-Carbide flails with plane and cutting edge made from carbide steel to ensure a long life clean cut and maximum shredding using less power
  • Well balanced Rotor with specially formed flail lugs to protect against damages from obstacles and bearings protected against dirt, wear and tear
  • Self-cleaning Roller with well-rounded edges to preserve the soil and turf and to carry the mulcher, adjustable to different heights;
  • Hardox Wearing skids
  • Optimised distance between the outer rotor circle and the roller guarantees perfect contour following and an even quality of cut
  • Adjustable Vario Cutting Bar


  • Specially designed multi position A-Frame Cat. 0 for Front mounting with mechanical side shift; Mounting position near to the tractor, A-Frame adaptable to different positions – in combination with gear box with integrated overrun-clutch mounted in front of the hood for 1.000 / 2.000 r.p.m.
  • Specially designed Head-Stock Cat. I only for Front-mounting, shiftable – in combination with gear box mounted in front of the hood with integrated overrun-clutch and through-drive for 1,000 / 2,000 r.p.m
  • Different r.p.m. to be asked for
  • Hydraulic side shift ( 1 double acting hydraulic connector needed ) – Left or Right build ( please state )
  • Second patented shark fin shredding bar.
  • Strong, height-adjustable rubber wheels, 360º swivel in front of the mulcher
  • Wearing plate inside the hood ( additional weight from around 20 kg (120 cm) up to 35 kg (200 cm )
  • Shackle M Carbide flails

Model WW
Tractor HP
540 r.p.m.
of flails
MU-E 120 120 135 60 280 20
MU-E 140 140 155 60 300 24
MU-E 160 160 182 60 330 28
MU-E 180 180 195 60 360 32
MU-E 200 200 215 60 390 36
